Cisco NCS 1002 System Setup And Software Installation Guide

Perform Clock Synchronization with NTP Server
There are independent system clocks for the XR and the System Admin. To ensure that these clocks do not
deviate from true time, they need to be synchronized with the clock of a NTP server. In this task you will
configure a NTP server for the XR. After the XR clock is synchronized, the System Admin clock automatically
synchronizes with the XR clock.
Before you begin
Configure and connect to the management port.
Procedure
Step 1 configure
Example:
RP/0/RP0/CPU0:ios# configure
Enters XR Configuration mode.
Step 2 ntp server server_address
Example:
RP/0/RP0/CPU0:ios# ntp server 64.90.182.55
The XR clock is configured to be synchronized with the specified sever.
System Setup and Software Installation Guide for Cisco NCS 1002
16
Bring-up Cisco NCS 1002
Perform Clock Synchronization with NTP Server
