1.2.6 Perform a Hairpin Test on a Destination-Node Electrical Port (East to West)
Step 4 If the test set indicates a faulty circuit, assume the cross-connect card is not causing the problem. Clear
the hairpin circuit:
a. Click the Circuits tab.
b. Choose the hairpin circuit being tested.
c. Click Delete.
d. Click Yes in the Delete Circuits dialog box. Do not check any check boxes.
e. Confirm that the hairpin circuit is deleted form the Circuits tab list.
Step 5 To confirm a defective original cross-connect card, complete the “Retest the Original XC-VXL
Cross-Connect Card” procedure on page 1-31.
Retest the Original XC-VXL Cross-Connect Card
Step 1 Initiate an external switching command (side switch) on the XC-VXL cross-connect cards:
a. Determine the standby cross-connect card. On both the physical node and the CTC node view
window, the standby cross-connect ACT/STBY LED is amber and the active card ACT/STBY LED
is green.
b. In node view, select the Maintenance > Cross-Connect > Card tabs.
c. From the Cross-Connect Cards menu, choose Switch.
d. Click Yes in the Confirm Switch dialog box.
Note After the active cross-connect goes into standby mode, the original standby card becomes
active and its ACT/STBY LED turns green. The former active card becomes standby and its
ACT/STBY LED turns amber.
Step 2 Resend test traffic on the loopback circuit.
Step 3 If the test set indicates a faulty circuit, the problem is probably the defective card. Return the defective
card to Cisco through the RMA process. Log into the Cisco Technical Support Website at
http://www.cisco.com/techsupport for more information or log into
http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml to obtain a directory of toll-free Cisco
TAC numbers for your country.
Step 4 Proceed to Step 5. If the test does not indicate a faulty circuit, proceed to Step 6.
Step 5 Complete the “Physically Replace an In-Service Cross-Connect Card” procedure on page 2-271 for the
defective cross-connect card.
Step 6 If the test set indicates a good circuit, the cross-connect card might have had a temporary problem that
was cleared by the side switch. Clear the hairpin circuit:
a. Click the Circuits tab.
b. Choose the hairpin circuit being tested.
c. Click Delete.
d. Click Yes in the Delete Circuits dialog box. Do not check any check boxes.
e. Confirm that the hairpin circuit is deleted form the Circuits tab list.
