Chapter 1 General Troubleshooting
1.6.5 Performance Monitoring Counters and Threshold Crossing Alerts
Figure 1-42 Set Default BBE/SES Card Thresholds
Step 2
In the Defaults Selector field, select Txp_mr_2_5g > otnthresholds > Trunk > pm > 15min.
Complete the following procedure to provision BBE or SES PM thresholds in CTC for an individual
TXP card.
Provision Individual Card BBE or SES Thresholds in CTC
Step 1 In node view, double-click the TXP_MR_2.5G card.
Note In this example, other transponder and muxponder cards are also applicable, such as
TXP_MR_10G, TXPP_MR_2.5G, and MXP_2.5G_10G.
Step 2 Click the Provisioning > OTN > G.709 Thresholds tabs (Figure 1-43).
