Chapter 1 General Troubleshooting
1.5.4 Perform a Terminal (Inward) Loopback on Intermediate-Node MXP/TXP/FC_MR Ports
Step 4 Complete the “Test and Clear the MXP/TXP/FC_MR Terminal Loopback Circuit” procedure on
page 1-90.
Test and Clear the MXP/TXP/FC_MR Terminal Loopback Circuit
Step 1 If the test set is not already sending traffic, send test traffic on the loopback circuit.
Step 2 Examine the test traffic being received by the test set. Look for errors or any other signal information
that the test set is capable of indicating.
Step 3 If the test set indicates a good circuit, no further testing is necessary on the loopback circuit. Clear the
terminal loopback from the port:
a. Double-click the intermediate-node card with the terminal loopback to display the card view.
b. Click the Maintenance > Loopback tab.
c. Select None from the Loopback Type column for the port being tested.
d. Select the appropriate state (Unlocked; Locked,disabled; Unlocked,automaticInService) in the
Admin State column for the port being tested.
e. Click Apply.
f. Click Yes in the confirmation dialog box.
Step 4 Complete the “Test the MXP/TXP/FC_MR Card” procedure on page 1-90.
Test the MXP/TXP/FC_MR Card
Step 1 Complete the “Physically Replace a Traffic Card” procedure on page 2-271 for the suspected bad card
and replace it with a known-good one.
Caution Removing a card that currently carries traffic on one or more ports can cause a traffic hit. To avoid this,
perform an external switch if a switch has not already occurred. See the “2.10.2 Protection Switching,
Lock Initiation, and Clearing” section on page 2-260 for basic instructions. For detailed information,
refer to the Cisco ONS 15454 SDH Procedure Guide Chapter 15, “Maintain the Node.”
Step 2 Resend test traffic on the loopback circuit with a known-good card.
Step 3 If the test set indicates a good circuit, the problem was probably the defective card. Return the defective
card to Cisco through the RMA process. Log into the Cisco Technical Support Website at
http://www.cisco.com/techsupport for more information or log into
http://www.cisco.com/warp/public/687/Directory/DirTAC.shtml to obtain a directory of toll-free Cisco
TAC numbers for your country.
Step 4 Complete the “Physically Replace a Traffic Card” procedure on page 2-271 for the defective card.
Step 5 Clear the terminal loopback on the port:
a. Double-click the source-node card with the terminal loopback.
b. Click the Maintenance > Loopback tab.
c. Select None from the Loopback Type column for the port being tested.
