1.5.2 Perform a Terminal (Inward) Loopback on a Source-Node MXP/TXP/FC_MR Port
Step 4 Click the Maintenance > Loopback tab.
Step 5 Select Locked,maintenance from the Admin State column. If this is a multiport card, select the row
appropriate for the desired port.
Step 6 Select Terminal (Inward) from the Loopback Type column. If this is a multiport card, select the row
appropriate for the desired port.
Step 7 Click Apply.
Step 8 Click Yes in the confirmation dialog box.
Step 9 Complete the “Test and Clear the MXP/TXP/FC_MR Port Terminal Loopback Circuit” procedure on
page 1-85.
Test and Clear the MXP/TXP/FC_MR Port Terminal Loopback Circuit
Step 1 If the test set is not already sending traffic, send test traffic on the loopback circuit.
Step 2 Examine the test traffic being received by the test set. Look for errors or any other signal information
that the test set is capable of indicating.
Step 3 If the test set indicates a good circuit, no further testing is necessary on the loopback circuit. Clear the
terminal loopback state on the port:
a. Double-click the card in the source node with the terminal loopback.
b. Click the Maintenance > Loopback tab.
c. Select None from the Loopback Type column for the port being tested.
d. Select the appropriate state (Unlocked; Locked,disabled; Unlocked,automaticInService) in the
Admin State column for the port being tested.
e. Click Apply.
f. Click Yes in the confirmation dialog box.
Step 4 Complete the “Test the MXP/TXP/FC_MR Card” procedure on page 1-85.
Test the MXP/TXP/FC_MR Card
Step 1 Complete the “Physically Replace a Traffic Card” procedure on page 2-271 for the suspected bad card
and replace it with a known-good one.
Caution Removing a card that currently carries traffic on one or more ports can cause a traffic hit. To avoid this,
perform an external switch if a switch has not already occurred. See the “2.10.2 Protection Switching,
Lock Initiation, and Clearing” section on page 2-260 for basic instructions. For detailed information,
refer to the Cisco ONS 15454 SDH Procedure Guide Chapter 15, “Maintain the Node.”
Step 2 Resend test traffic on the loopback circuit with a known-good card.
