Cisco ONS 15454 Series Reference Manual

EC-1
DS3XM-6
DS3XM-12
Slot 3
Slot 4
Slot 5
Slot 6
Slot 14
Slot 15
Slot 16
Slot 17
AMP
Champ
DS-1
6 AMP
Champ
connectors
Slot 1
Slot 2
Slot 3
Slot 4
Slot 5
Slot 6
15454-EIA-1AMPA84=
6 AMP
Champ
connectors
Slot 12
Slot 13
Slot 14
Slot 15
Slot 16
Slot 17
15454-EIA-1AMPB84=
UBIC-V
DS-1
DS-3
EC-1
DS3XM-6
DS3XM-12
DS3/EC1-48
DS1/E1-56
8 pairs of
SCSI
connectors
Slot 1
Slot 2
Slot 3
Slot 4
Slot 5
Slot 6
15454-EIA-UBICV-A
8 pairs of
SCSI
connectors
Slot 12
Slot 13
Slot 14
Slot 15
Slot 16
Slot 17
15454-EIA-UBICV-B
UBIC-H
DS-1
DS-3
EC-1
DS3XM-6
DS3XM-12
DS3/EC1-48
DS1/E1-56
8 pairs of
SCSI
connectors
Slot 1
Slot 2
Slot 3
Slot 4
Slot 5
Slot 6
15454-EIA-UBICH-A
8 pairs of
SCSI
connectors
Slot 12
Slot 13
Slot 14
Slot 15
Slot 16
Slot 17
15454-EIA-UBICH-B
BNC EIA
The ONS 15454 BNC EIA supports 24 DS-3 circuits on each side of the ONS 15454 (24 transmit and 24
receive connectors). If you install BNC EIAs on both sides of the shelf assembly, the ONS 15454 hosts up to
48 circuits. The BNC connectors on the EIA supports Trompeter UCBJ224 (75-ohm) 4-leg connectors (King
or ITT are also compatible). Right-angle mating connectors for the connecting cable are AMP 413588-2
(75-ohm) connectors. If preferred, you can also use a straight connector of the same type. Use RG-59/U cable
to connect to the ONS 15454 BNC EIA. These cables are recommended to connect to a patch panel and are
ONS_15454_Reference_Manual_R8.5.x_--_Shelf_and_Backplane_Hardware
Table 1-2: EIA Configurations Compatible with the 15454-SA-ANSI and the 15454-SA-HD 17

Cisco ONS 15454 Series Specifications

General

Supported Interfaces	Ethernet
Management	Cisco Transport Controller (CTC), TL1, SNMP
Power Supply	-48 VDC or AC (depending on power supply module)
Operating Temperature	0 to 50°C (32 to 122°F) - varies by module
Storage Temperature	-40°C to 70°C (-40 to 158°F)
Relative Humidity	5 to 95%, noncondensing
Supported Protocols	SONET/SDH, Ethernet, OTN
Platform Type	Multi-service transport platform
