Tx Tip 14
black/brown
Tx Ring 14
brown/black
Rx Tip 14
black/brown
Rx Ring 14
brown/black
Tx Tip 15 black/slate 15 47 Tx Tip 15 slate/black Rx Tip 15 black/slate 31 63 Rx Tip 15 slate/black
Tx Tip 16
yellow/blue
16 48 Tx Tip 16 blue/yellow
Rx Tip 16
yellow/blue
32 64 Rx Tip 16 blue/yellow
When using DS-1 AMP Champ cables, you must equip the ONS 15454 with an AMP Champ connector EIA
on each side of the backplane where DS-1 cables will terminate. Each AMP Champ connector on the EIA
corresponds to a slot in the shelf assembly and is numbered accordingly. The AMP Champ connectors have
screw-down tooling at each end of the connector.
UBIC-V EIA
UBIC-V EIAs are attached to the shelf assembly backplane to provide up to 112 transmit and receive
connections through 16 SCSI connectors per side (A and B). The UBIC-V EIAs are designed to support
DS-1, DS-3, and EC-1 signals. The appropriate cable assembly is required depending on the type of signal.
You can install UBIC-Vs on one or both sides of the ONS 15454. As you face the rear of the ONS 15454
shelf assembly, the right side is the A side (15454-EIA-UBICV-A) and the left side is the B side
(15454-EIA-UBICV-B). The diagrams adjacent to each row of SCSI connectors indicate the slots and ports
that correspond with each SCSI connector in that row, depending on whether you are using a high-density
(HD) or low-density (LD) configuration.
UBIC-V EIAs will support high-density electrical cards (DS3/EC1-48, DS1/E1-56), as well as low-density
electrical cards.
Figure 1-20 shows the A- and B-side slot assignments.
Figure 1-20: UBIC-V Slot Designations
