17
DS-1 1-14 - - - - - - -
DS-3 1-12 - - - - - - -
16
DS-1 - - - - 1-14 - - -
DS-3 - - - - 1-12 - - -
15
DS-1 - - - - - - 1-14 -
DS-3 - - - - - - 1-12 -
14
DS-1 - - - - - 1-14 - -
DS-3 - - - - - 1-12 - -
13
DS-1 - 1-14 - - - - - -
DS-3 - 1-12 - - - - - -
12
DS-1 - - 1-14 - - - - -
DS-3 - - 1-12 - - - - -
Tables 1-13 and 1-14 show the J-labeling and corresponding card ports for a shelf assembly configured with
high-density 48-port DS-3/EC-1 or 56-port DS-1 electrical cards.
Table 1-13: J-Labeling Port Assignments for a Shelf Configured with High-Density Electrical Cards (A Side)
Slot Port Type TX J4 J3 J2 J1 J5 J6 J7 J8
RX J12 J11 J10 J9 J13 J14 J15 J16
Ports Ports Ports Ports Ports Ports Ports Ports
1
DS-1 1-14 15-28 29-42 43-56 - - - -
DS-3 1-12 13-24 25-36 37-48 - - - -
2
DS-1 - - - - 1-14 15-28 29-42 43-56
DS-3 - - - - 1-12 13-24 25-36 37-48
Table 1-14: J-Labeling Port Assignments for a Shelf Configured with High-Density Electrical Cards (B Side)
Slot Port Type TX J20 J19 J18 J17 J21 J22 J23 J24
RX J28 J27 J26 J25 J29 J30 J31 J32
Ports Ports Ports Ports Ports Ports Ports Ports
17
DS-1 1-14 15-28 29-42 43-56 - - - -
DS-3 1-12 13-24 25-36 37-48 - - - -
16
DS-1 - - - - 1-14 15-28 29-42 43-56
DS-3 - - - - 1-12 13-24 25-36 37-48
If you are installing UBIC-H EIAs after the shelf assembly is installed, plug the UBIC-H EIA into the
backplane. The UBIC-H backplane must replace the standard sheet metal cover to provide access to the cable
connectors. The UBIC-H sheet metal covers use the same screw holes as the standard sheet metal covers, but
they have 12 additional holes for panhead screws and three holes for jack screws so you can screw down the
cover and the board using standoffs on the UBIC-H board.
When installed with the standard door and cabling on the backplane, the ONS 15454 shelf measures
approximately 14.5 inches deep when fully populated with backplane cables, and 15.0 inches deep with the
rear cover installed. When installed with the deep door and cabling on the backplane, the ONS 15454 shelf
measures approximately 16.5 inches deep when fully populated with backplane cables, and 17.0 inches deep
with the rear cover installed.
The UBIC-H EIA supports the following cards:
DS1-14, DS1N-14
ONS_15454_Reference_Manual_R8.5.x_--_Shelf_and_Backplane_Hardware
Table 1-12: J-Labeling Port Assignments for a Shelf Assembly Configured with Low-Density Electrical Cards (B Side)33
