1-32
Cisco ONS 15454 Procedure Guide, R4.0
March 2003
Chapter 1 Install the Shelf and Backplane Cable
NTP-A119 Install the Alarm Expansion Panel
Figure 1-12 Replace Backplane Screws with Standoffs
Step 2 Attach the remaining two standoffs on either side of the backplane (Figure 1-13).
Step 3 Position the AEP board over the standoffs (Figure 1-13).
78402
Longer
Shorter
