Administration: Discovery
Discovery - CDP
154 Cisco 350, 350X and 550X Series Managed Switches, Firmware Release 2.4, ver 0.4
9
• Edit—Fields explained in Step 2 below.
• CDP Local Information Details—Takes you to the CDP Local Information page.
• CDP Neighbor Information Details—Takes you to the CDP Neighbors Information
page.
STEP 2 Select a port and click Edit.
This page provides the following fields:
• Interface—Select the interface to be defined.
• CDP Status—Select to enable/disable the CDP publishing option for the port.
NOTE The next three fields are operational when the device has been set up to send
traps to the management station.
• Syslog Voice VLAN Mismatch—Select to enable sending a SYSLOG message when
a voice VLAN mismatch is detected. This means that the voice VLAN information in
the incoming frame does not match what the local device is advertising.
• Syslog Native VLAN Mismatch—Select to enable sending a SYSLOG message when
a native VLAN mismatch is detected. This means that the native VLAN information in
the incoming frame does not match what the local device is advertising.
• Syslog Duplex Mismatch—Select to enable sending a SYSLOG message when duplex
information mismatch is detected. This means that the duplex information in the
incoming frame does not match what the local device is advertising.
STEP 3 Enter the relevant information, and click Apply. The port settings are written to the Running
Configuration.
CDP Local Information
To view information that is advertised by the CDP protocol about the local device:
STEP 1 Click Administration > Discovery - CDP > CDP Local Information.
STEP 2 Select a local port, and the following fields are displayed:
• Interface—Number of the local port. The OOB port can also be selected.
• CDP State—Displays whether CDP is enabled or not.
• Device ID TLV
