Cisco UCS Administration Guide

2-2
Cisco UCS Invicta Scaling System Administration and Configuration Guide, Version 5.0.1.1a
OL-31372-01
Chapter 2 Home
Main Dashboard
Step 5 Click OK and Apply.
Step 6 To run the scripts, click Refresh.
Overview Tab
The Overview tab is a graphical representation of the SSRs, SSNs, in the Cisco UCS Invicta Scaling
System. It shows how the devices are physically connected and uses color coding to reflect health status.
It displays:
• SSR. The SSR into which you are logged-in is represented.
Note The SSR stack is for current SSR identification only. You cannot switch to another SSR without logging
into it.
• SSNs. The SSNs are displayed in a scrolling carousel. You can click an SSN to view Performance
MB/s, IOPS and Latency monitors and an system wear indicator.
You can also perform various drive operations which are described in this chapter.
Node RAID Health
Figure 2-1and Figure 2-2 provide legends for the colors of the RAID and Drive Status:
Figure 2-1 RAID Status Legend
