Cisco VG310 User Manual

Using Cisco Configuration Professional Express 58
Using Cisco IOS CLI—Manual Configuration 58
Troubleshooting Cisco VG310 and Cisco VG320 59
CHAPTER 5 Getting Software Licenses for Cisco VG310 and Cisco VG320 Voice Gateways 61
Activating a New Software Package or Feature 61
RMA License Transfer 62
APPENDIX A Technical Specifications 63
Physical Specifications 63
Power Specifications 64
Ports 64
Environmental Specifications 65
Acoustic 65
Transportation and Storage 65
Regulatory Compliance 66
APPENDIX B Cable Specifications and Information 69
Console and Auxiliary Port Signals and Pinouts 69
Console Port Signals and Pinouts 70
Auxiliary Port Signals and Pinouts 71
Identifying a Rollover Cable 72
Console Port to ASCII Terminal 72
Gigabit Ethernet Connector Pinouts (RJ-45) 73
ISDN BRI Interface 74
ISDN BRI Connections 74
ISDN BRI Pinouts 75
E&M Pinouts 76
Analog Voice RJ-21 Pinouts 77
Serial Connection Signals and Pinouts 79
Connecting the WIC to the Network 79
EIA/TIA-232 Connections 79
EIA/TIA-449 Connections 80
V.35 Connections 80
X.21 Connections 81
Cisco VG310 and Cisco VG320 Voice Gateways Hardware Installation Guide
vi OL-31292-01
Contents

Cisco VG310 Specifications

General

Number of Ports	24 FXS ports
Network Protocols	SIP, MGCP, H.323
Form Factor	Rack-mountable
Operating Temperature	32 to 104°F (0 to 40°C)
Storage Temperature	-4 to 149°F (-20 to 65°C)
Power Supply	AC 100 to 240 VAC, 50 to 60 Hz
Ethernet Ports	2 x 10/100/1000 Ethernet ports
Humidity	10 to 90% non-condensing
Compliance	FCC, CE, UL
