Ciscomotors SNAP 100 User Manual

Pag.17
Decarbonizing
COMBUSTION CHAMBER
Remove the carbon deposits from the combustion chamber. Clean the head gasket surface of any
gasket material
CAUTION:
Use care not to scratch the combustion chamber or the head gasket surface.
CYLINDER
Clean carbon deposits from the exhaust.
CAUTION:
Do not damage the cylinder bore.
INSTALLATION PISTON
Fig.14
1. Install the piston rings like (Fig.14)
2. Lubricate the piston rings and piston ring
grooves with clean 2 stroke oil
3. Install the piston with the sign turned
towards the exhaust (Fig.15)
4. Install the piston pin (Fig.12)
5. Install the piston rings on the piston
(Fig.11)
Fig. 15
CAUTION:
• Use new pin clips. Never use old clips
• Do not let the clips fall into the crankcase.
