Ciscomotors SNAP 100 User Manual

Pag. 21
6.4 DISASSEMBLY/ ASSEMBLY SILENCER
1. Remove the exhaust like chapter 6.2
2. Remove the 3 bolts and cap screw fixing
silencer (Fig,.22)
3. Remove the glass wool
4. Remove the carbon deposite from the
inner pipe using the wire brush
1. Repalce the glass wool
2. Install the new glass wool packing
material, opening the incision of the glass
wool
NOTE :
be carefull not to damage the glass wool
3 . Tighten the 3 bolts and cap screw to the
specified torque
TORQUE : 12Nm( 1,2 kgf/m)
Fig.22
