Pag.29
3. THE ENGINE VIBRATES EXCESSIVE
CHECK POSSIBLE CAUSES SOLUTION
Excessive wear, holder rubber Repalce (Max 70 Sh)
Silent-block engine
Prop out of balance Balance or replace
9. TORQUE VALUES ENGINE
ITEM
Thread diam x
pitch
Torque
gf*m
Cap screw propeller hub M 6 x 1,0 1.2
Spark plug M14 x 1,25 1,8
Cap screw cooling air duct M 5 x 0.8 0,6
Cap screw crankcase starter M 5 x 0,8 0,6
Bolt cylinder head M 7 x 1,0 1,2
Cap screw riducer/engine M 6 x 1,0 1,1
Cap screw crankcase reducer M 6 x 1,0 1,2
*Bolt clutch bell M 10 x 1.25 3,8
*Bolt clutch M 10 x 1.25 3,8
All bolts M 6 x 1,0 0,9
*Bolts ignition M 10 x 1.25 4,0
* Apply locking agent
