General Specifications
1-3 CL-S6621
1-1. General Specifications
Printing
Printing method Thermal transfer/Direct thermal
Main scanning line density: 203 dots/inch (8 dots/mm)
Sub-scanning line density: 203 dots/inch (8 dots/mm)
Resolution
Head 1344 dots (effective dots: 1344 dots)
Max. print width 168 mm 6.6inch
Max. print length 2539.7 mm 99.99 inch
Print density Print density is adjustable with software
Printing speed setting 6, 5, 4, 3 or 2 inches per second
Print mode
Batch mode Normal printing (single or multiple sheets)
Tear off mode Feeds back media to the tear-off position after printing is completed.
Cut mode *
1
Prints while cutting at designated sheet units.
The following two kinds of cut mode operations are available.
• Back feed
• Cut through
(Cut through refers to stopping present printing to cut the previous
label when it reaches the cut position. After cutting, printing restarts
but a gap may be created at the seam of the printing at this time.)
Peel mode*
1
Peels labels from the liners after printing them.
Media
Types of media Roll, fanfold
(continuous media, die-cuts, continuous tags, paper or tickets)
Recommended media Thermal transfer: label media (LR1111 Lintec)
Direct thermal media: label media (150LA-1 Ricoh),
tag media (130LHB Ricoh)
Max. media width 178.0 mm 7.01"
Min. media width 50.0 mm 1.97"
Min. label width 50.0 mm 1.97"
Min. label pitch*
2
19.0 mm 0.748"
Max. media thickness 0.254 mm 0.01"
Max. media length 2539.7 mm 99.99"
Min. media length 16.0 mm 0.63"
Min. media thickness 0.0635 mm 0.0025"
Max. external diameter: 127mm 5" On-board roll media
diameter
Media core: 25.4 to 76mm
Min. media core external diameter
(when using label media): 50.8 mm
1 to 3"
2"
*1: Options can be separately purchased.
*2: When a media pitch of less than 1" is used, set the "Small Media Adjustment" setting in the
"Page Setup" menu to "On".
