Citizen CL-S6621 - Disassembly, Reassembly and Lubrication

Disassembly, Reassembly and Lubrication
3-9 CL-S6621
3-6. Disassembly, Reassembly and Lubrication
[Disassembly Flowchart for Major Parts]
Roll Paper Shaft
SA, Head
SA2 Platen
Cover Top
Unit, Ribbon
SA Ribbon Motor R
SA Ribbon Motor F
SA, Ribbon Sensor
SA, Ribbon PCB
Ribbon Gears
Case U
SA, Opepane PCB
Unit, Power Supply
Cover Main PCB
SA PNE Sensor
SA, Relay PCB
SA, Main PCB
CL-S6621
Unit, Mechanism
SA2 Platen
Unit, Sensor U SA TRA Sen PCB
(See 3-5-1.)
(See 3-5-2.)
(See 3-6-1.)
(See 3-6-5.)
(See 3-6-6.)
(See 3-6-6.)
(See 3-6-9/10.)
(See 3-6-6.)
(See 3-6-13(2).)
(See 3-6-3.)
(See 3-6-12.)
(See 3-6-2.)
(See 3-6-11(2).)
(See 3-6-11(3).)
(See 3-6-11(3).)
(See 3-6-11(3).)
(See 3-6-13(1).)
(See 3-6-14.)
(See 3-6-13(3).)
SA PF Motor
SA Ref Sen PCB
SA, Head Up Switch
(See 3-6-20(2).)
(See 3-6-20(1).)
(See 3-6-19.)
(See 3-6-15.)
(See 3-6-16.)
Unit, Power Supply Case L
(See 3-6-13(2).)
(See 3-6-17.)
Unit, Head SA, Head
(See 3-6-18.)
(See 3-6-24.)
SA, Fan
(See 3-6-4.)
