2-3. Operation Panel
2-47 CLP-621 & CLP-631
(b) Service Mode menu table
Submenu Name Value Description
Head Check None [PAUSE]: Checks the number of defective
thermal elements and prints it. If no
defective thermal element is found,
ā€œ0ā€ will be printed.
Example:
Bad head element : 0 dot(s)
[STOP]: Nothing is printed.
ROM Check None [PAUSE]: Performs ROM checksum test, and
prints the check result (OK or NG)
and the checksum value.
Example:
PROGRM ROM OK 4F4E
[STOP]: Nothing is printed.
RAM Check None [PAUSE]: Performs RAM capacity check and
prints the check result.
Example: RAM OK 16384K
[STOP]: Nothing is printed.
Cutter Check None [PAUSE]: Performs cutter operation check once.
(Optional)
[STOP]: Nothing is done.
Print Counter None [PAUSE]: Prints the total printed length since
the printer is firstly used.
Example: Length 1234.567Km
[STOP]: Nothing is printed.
Service Counter None [PAUSE]: Prints the service counter length in
Km since you reset it last.
Example:
Length 0123.456Km
Clear Service Counter ?
Yes=(PAUSE) No=(STOP)
To clear the service counter, press
the [PAUSE] key again. To quit, press
the [STOP] key.
[STOP]: Nothing is printed.
