114
Ease of use and comfort
Jumpy_en_Chap03_ergonomie-et-confort_ed01-2016
F If your vehicle has the facility, place the
backrest in the table position.
F Tip the seat forward.
F
Using the handle, release the rear feet then
tip the seat forward.
F To return the seat to the normal position,
unfold the seat backwards until the rear
feet engage in their anchorages.
F
If your vehicle has the facility, place the
backrest in the table position.
Fully folding a seat, access to row 3
(example of an individual seat)
Removing a seat
(example of an individual seat)
It is not necessary to fold the backrest
(table position) to tip the bench seat for
access to row 3.
F Fold the backrest onto the cushion.
F
To return the backrest to the normal
position, raise the lever and pull the
backrest up (from the rear, lower the lever).
F
Release the front feet using the handles.
F
Disengage the seat from its anchorages.
F
Remove the seat by the sliding door in
row
2 or from the rear in row 3.
