Clarion SR1000 - Primary Harness (H1), 12-Pin Connector; Default Chapter; Auxiliary Harness (H2), 6-Pin Connector

14
primary harness (H1), 12-pin connector
______
______
______
______
______
______
______
______
______
______
______
______
auxiliary harness (H2), 6-pin connector
______
______
______
______
______
______
LIGHT BLUE (-) SECOND UNLOCK OUTPUT
WHITE/BLACK PROGRAMMABLE CHANNEL 5
VIOLET/BLACK PROGRAMMABLE CHANNEL 4
GREEN/WHITE FACTORY REARM
GREY/BLACK WAIT TO START
LIGHT GREEN/BLACK (-) FACTORY DISARM
H2/1
H2/2
H2/3
H2/4
H2/5
H2/6
RED/WHITE (-) 200 mA CHANNEL 2 VALIDITY OUTPUT
RED (+) CONSTANT POWER INPUT
BROWN (+) SIREN OUTPUT
EMPTY NOT USED
BLACK (-) CHASSIS GROUND INPUT
VIOLET (+) DOOR TRIGGER INPUT, ZONE 3
BLUE (-) MULTIPLEXED INPUT, ZONE 4
GREEN (-) DOOR TRIGGER INPUT, ZONE 3
BLACK/WHITE (-) 200 mA DOMELIGHT SUPERVISION OUTPUT
WHITE/BLUE (-) REMOTE START ACTIVATION INPUT
WHITE (+)/(-) SELECTABLE LIGHT FLASH OUTPUT
ORANGE (-) 500 mA ARMED OUTPUT
H1/1
H1/2
H1/3
H1/4
H1/5
H1/6
H1/7
H1/8
H1/9
H1/10
H1/11
H1/12
