3 – 13
2) Replacing contact point of steering EPS contactor
a Separate the contactor installation bolt
from the contactor assembly.
b Pull the contact points and the coils
of contactor with hands in order to
separate.
c Remove the relevant contact point
from the contact point of contactor,
and replace it with new one.
d Mount the contactor to the the
machine after assembling as original
condition.
24. GUIDE TO REPLACE AND REPAIR PARTS
Screw
Nut
Contac-A
Contac-Com
Coil
FX1085
