7.2
ESX 12 - 25
ESX 12-25
Clark products and specifi cation are subject to improvements and changes
without notice or obligation.
Model Designation — Rated Load Capacity
ESX12 2,500 lbs @ 24 in [1250 kg @ 500 mm]
ESX15S 3,000 lbs @ 24 in [1500 kg @ 500 mm]
ESX15 3,000 lbs @ 24 in [1500 kg @ 500 mm]
ESX17 3,500 lbs @ 24 in [1750 kg @ 500 mm]
ESX20 4,000 lbs @ 24 in [1815 kg @ 500 mm]
ESX22 4,500 lbs @ 24 in [2250 kg @ 500 mm]
ESX25 5,000 lbs @ 24 in [2270 kg @ 500 mm]
Note: Specifi cations are given with triple stage upright, standard battery compart-
ment size and minimum battery weight.
Truck Weights (approximate, with standard upright, Min. battery wt.)
Service Wt. Drive Axle Loading Steer Axle Loading
w/o load w/o load w/load w/o load w/load
ESX12
8425[3822kg] 4266[1935kg] 8911[4042kg] 4159[1886kg] 2014[914kg]
ESX15S
8735[3962kg] 4404[1998kg] 9975[4525kg] 4331[1965kg] 1757[797kg]
ESX15
9055[4107kg] 4527[2053kg] 9987[4530kg] 4528[2054kg] 2068[938kg]
ESX17
9417[4271kg] 4659[2113kg] 10878[4934kg] 4758[2158kg] 2040[925kg]
ESX20
9752[4423kg] 4779[2168kg] 11731[5321kg] 4973[2256kg] 2021[917kg]
ESX22
10071[4568kg] 4814[2184kg] 12507[5673kg] 5257[2385kg] 2064[936kg]
ESX25
10686[4847kg] 5106[2316kg] 13673[6202kg] 5580[2531kg] 2013[913kg]
Tires
Note: Wide drive recommended for attachments capable of offsetting
loads more than 4” (100mm) in each direction, left or right.
ESX 12/15S/15 - 18x7x12.1
Smooth cushion rubber - Drive
Lug type cushion - Drive
Non-marking rubber - Drive
Polyurethane - 18x6x12.1 - Drive
Solid pneumatic - 18x7 - Drive
Note: Solid pneumatic tires may reduce capacity
ESX 17/20 - 18x8x12.1
Smooth cushion rubber - Drive
Lug type cushion - Drive
Non-marking rubber - Drive
Polyurethane - 18x6x12.1 - Drive
Solid pneumatic -18x9- Drive
Note: Solid pneumatic tires may reduce capacity
