Section 7. Specifi cations
7.3
NLGI Grade No. 1 Lithium soap base grease
CLARK Specifi cation MS-9B and MS-107B.
NLGI Grade No. 2 Lithium soap base grease,
CLARK Specifi cation MS-107C.
Steering linkage, upright
mast & carriage rollers,
trunnion bushings, tilt cyl-
inder rod ends, brake pedal
shaft
:
ESX 22/25 - 18x9x12.1
Smooth cushion rubber - Drive
Lug type cushion - Drive
Non-marking rubber - Drive
Polyurethane - 18x7x12.1 - Drive
ESX 12/25 - Wide Drive - 18x9x12.1
Smooth cushion rubber - Wide Drive
Lug type cushion – Wide Drive
Non-marking rubber – Wide Drive
Siped Polyurethane – 18x9x12.1 – Wide Drive
Steer Tires (All Models)
Urethane
9x5x5 (2 per truck)
Battery Capacity Range
36 volt, 18 cells, 20.9-43.0 kWh, 600-1240 amp hr @6 hr rating Battery, fully
charged: 1.275 specifi c gravity (1.310 Exide Load Hog)
Discharged: 1.160 to 1.120 specifi c gravity
Battery Capacity Range
48 volt, 24 cells, 20.9-43.0 kWh, 600-1240 amp hr @6 hr rating Battery, fully
charged: 1.275 specifi c gravity (1.310 Exide Load Hog)
Discharged: 1.160 to 1.120 specifi c gravity
Fill Capacities—Fluid Volumes
Drive Axle: 6.8 quarts (6.44L)
Hydraulic Sump Tank (Usable Volume): 3.35 gal (12.68L)
Hydraulic Fluid Recommendation
Normal application - CLARK Specifi cation MS-68 Hydraulic oil
Cold Storage or low temp. - CLARK Specifi cation MS-226 Hydraulic oil
Drive Axle Fluid Recommendation: 80w-90 (Cold / Freezer 75w-90)
Use genuine CLARK parts. See your CLARK dealer.
ESX12-25
Axle Ends and wheel bear-
ings
