Clarke BSW 28 User Manual

- BSW 28
Parts List - BSW 28
75
Ref. Part No. Description Qty
1 146 3112 000 SCREW CYL HD THD FORM 4X30 2
2 33005603 NUT M5 1
3 08193000 CLAMP CABLE 1
4 08228600 WASHER FLAT 6X18 5
5 33005607 NUT SELFLOCKING M8 1
6 33005604 NUT HEX SELFLOCKING M6 3
7 08812590 SCREW PAN HD 4.6X19.2 4
8 33003977 SCREW HEX HD M6X30 3
9 33005915 WASHER FLAT 8X17 1
10 33003720 WASHER FLAT 2
11 145 9237 000 WASHER FLAT 4X12 5
12 146 2988 000 FILTER SUPPORT 1
13 146 2989 000 GASKET 1
14 146 2990 000 BRACKET BATTERY FIXING 1
15 146 2992 000 FILTER SHAKER HANDLE 1
16 146 2993 000 FILTER SHAKER 1
17 146 2090 000 SCREW CYL HD M5X16 1
18 145 0274 000 SPRING 1
19 145 9679 000 MICROSWITCH 1
20 146 0549 000 BUSHING FLANGED 2
21 1463176000 GASKET FILTER KIT 1
Dust Control System - 09/07
Ref. Part No. Description Qty
1 146 3112 000 SCREW CYL HD THD FORM 4X30 2
2 33005603 NUT M5 1
3# L08193000 CLAMP CABLE 1
4# L08228600 WASHER FLAT 6X18 5
5 33005607 NUT SELFLOCKING M8 1
6 33005604 NUT HEX SELFLOCKING M6 3
7# L08812590 SCREW PAN HD 4.6X19.2 4
8 33003977 SCREW HEX HD M6X30 3
9 33005915 WASHER FLAT 8X17 1
10 33003720 WASHER FLAT 2
11 145 9237 000 WASHER FLAT 4X12 5
12 146 2988 000 FILTER SUPPORT 1
13 146 2989 000 GASKET 1
14 146 2990 000 BRACKET BATTERY FIXING 1
15 146 2992 000 FILTER SHAKER HANDLE 1
16 146 2993 000 FILTER SHAKER 1
17 146 2090 000 SCREW CYL HD M5X16 1
18 145 0274 000 SPRING 1
19 145 9679 000 MICROSWITCH 1
20 146 0549 000 BUSHING FLANGED 2
21 1463176000 GASKET FILTER KIT 1
NOTE: # indicates a change has been made since th last pubblication of this manual

Clarke BSW 28 Specifications

General

Brand	Clarke
Model	BSW 28
Category	Floor Machine
Language	English
