Clarke Focus II User Manual

ENGLISH
8
Operator’s Manual - FOCUS
®
II L17 - S20 - L20 - L20 Cyl. - BOOST
®
L20
MACHINE DESCRIPTION
OUTER AND INNER STRUCTURE
(See Fig. 2)
Control panelA.
HandlebarB.
Brush/forward gear switch (*). Brush switch (***)C.
Speed adjuster (*)D.
Battery charger data inspection windowE.
Battery charger cableF.
Battery charger cable holderG.
Solution/clean water rear ller neckH.
Reverse gear switchI.
Squeegee lifting/lowering leverJ.
Deck lifting/lowering pedalK.
K1. Deck lifting
K2. Deck lowering
K3. Extra pressure activation (optional) (***)
Battery connector (red). This connector also works as L.
EMERGENCY switch, to stop immediately all functions.
Rear steering wheelM.
Front wheels on xed axle. Driving wheels (*)N.
Squeegee vacuum hoseO.
Recovery water drain hoseP.
Solution/clean water drain and level check hoseQ.
Deck with one brush/pad-holderR.
Deck with two cylindrical brushesS.
Brush/pad-holderT.
Solution/clean water tankU.
Recovery water tankV.
Recovery water tank coverW.
Can holderX.
Solenoid valveY.
SqueegeeZ.
Squeegee knobsAA.
Squeegee balance adjusting knobAB.
Machine straight forward movement adjusting pin AC.
Machine forward speed adjusting pin (***) AD.
Recovery water tank cover (open)AE.
Tank cover gasketAF.
Cover movable retaining plateAG.
Cover xed retaining plate (do not remove!)AH.
Serial number plate/technical dataAI.
Squeegee vacuum hose cleaning holeAJ.
Vacuum grid with automatic shut-off oatAK.
Solution/clean water front ller neckAL.
Grid lter (optional)AM.
Compensation holeAN.
Recovery water tank (open)AO.
Recovery water drain hose plugAP.
Tank safety cableAQ.
Vacuum system motor coverAR.
Vacuum system motor sound-deadening lterAS.
Detergent tank (**)AT.
Detergent tank ller plug (**)AU.
Detergent tank handle (**)AV.
Detergent feed hose (**)AW.
Detergent pump (**)AX.
Detergent tank - pump connecting hose (**)AY.
Detergent pump holder (**)AZ.
BatteriesBA.
Battery capsBB.
Solution lter BC.
Solution/clean water tapBD.
Reference table for detergent proportioning (**)BE.
Battery connection diagramBF.
(*) Only for FOCUS II L17 - L20 - L20 Cyl. - BOOST L20
(**) Only for machines with Chemical Mixing System (optional)
(***) Only for FOCUS II S20
B ENGLISH.indd 8 14/04/2010 12.47.51

Clarke Focus II Specifications

General

Cleaning Path	20 inches
Power Source	Battery
Brush Motor	0.75 hp
Battery Voltage	24 V
Voltage	36V
Vacuum Motor	0.5 hp
