Clarke
®
Operator's Manual IMAGE 26B Page -23-
1 51535A Bushing,
5
/8 x
3
/4 1
2 61685A Control, Brush Height 1
3 980645 Washer, Flat
3
/8 3
4 86207A Screw, Set
3
/8 -16 x 1 1
5 55537A Knob, Brush Pressure 1
6 85395A Screw, ¼-20 x ½ 12
7 69196A Top Rear Panel 1
8 737140 Quick Disconnect 1
9 64521A Hinge, Rear Panel 1
10 962980 Screw, 6-32 x
7
/8 2
11 47374A Switch, Straight Lever 1
12 920056 Nut, 6-32 ESNA 2
13 69386A Rear Panel 1
14 68796A Wear Plate 1
15 697501 Reducer, ¼NPT-
1
/8NPT 1
16 55167A Hosebarb,
3
/8 x ¼ 1
17 39102A Trim, Frame 1
18 65448A Brush Lift 1
19 81102A Nut, ¼-20 ESNA 6
20 65449A Link, Brush Lift 1
21 87618A Washer, Flat
3
/8 Nylon 5
22 608210 Spacer 1
23 60467A Arm, Brush Lift 1
24 60052A Retainer, Drain Valve 1
25 438360 Spring, Adjustor 1
26 980692 Washer, Flat
5
/16 SS 3
27 65447A Lift, Recovery Tool 1
28 80028A Bolt, Shoulder
5
/16 x 1 1
29 64490A Handle 1
Ref Part No. Description Qty
Clarke
®
Image 26B
Rear Panel Assembly and Parts List 8/03
30 64906A Handle, Recovery Tool Lift 1
31 980666 Washer, Starlock
3
/8 1
32 85389A Screw,
3
/8 -16 x
5
/8 1
33 85806A Screw, ¼-20 x
3
/4 3
34 87026A Washer, Flat ¼ 2
35 85700A Screw, ¼ x 20 x 1 2
36 41160B Control, Motor 1
37 85390A Screw, ¼" 1
38 30021A Trim, Frame
1
39 98465A Clamp, Insulated 1
40 857345 Snap Ring 1
41 962430 Screw 1
42 50249A Spacer 4
43 30089A Tank, Chemical 1
44 51209A Pin, Chemical Jug 1
45 51210A Knob, Chemical Tank 1
46 80134A Fitting, Swivel 1
47 10224A Cap Assembly (incl. 47A-C) 1
47A 52333A Hosebarb 1
47B 30090B Cap, Chemical Jug 1
47C 52419A Tip, Lt. Blue Metering 2 oz/gal
52828A Tip, Tan Metering 1 oz/gal
52829A Tip, Orange Metering 1.5 oz/gal
52831A Tip, Pink Metering 3 oz/gal
48 962968 Screw 4
49 81110A Nut 4
50 722021 Hose Clamp 1
NI 77366A Label 1
NI 77367A Label 1
Ref Part No. Description Qty
1
2
3
4
5
48
7
8
9
10
11
13
14
15
16
17
18
19
34
19
34
20
21
42
33
23
21
6
24
25
27
26
28
21
22
29
30
32
37
41
39
19
19
3
38
3
31
40
42
36
26
35
6
12
43
44
45
47A
47B
47C
46
47
19
49
6
50
33
