Clarke Image 26B User Manual

Page -26- Clarke
®
Operator's Manual IMAGE 26B
1 65979B Frame 1
2 85806A Screw, ¼-20x
3
/4 19
3 85811A Screw,
5
/16-18 6
4 58614A Spring 1
5 65507A Latch, Bridge 1
6 920208 Nut, ¼-20 9
7 85701A Screw, ¼-20 x 1½ 1
8 64907A Handle 1
9 62450A Clamp, Handle 2
10 980651 Washer, Flat
5
/16 4
11 920110 Nut,
5
/16-18 4
12 87026A Washer, Flat ¼ 20
13 55013A Hinge 1
14 61539A Bridge 1
15 69206A Wheels 2
16 50008C Transaxle 1
16A 52660A Coupler, Transaxle 1
16B 50252A Mount, Transaxle 1
Ref Part No. Description Qty
Clarke
®
Image 26B
Frame Assembly Drawing and Parts List 6/04
16C 50251A Motor, Brush 4
16D 50250B Motor, Transaxle 1
17 62435A Clamp, Transaxle 2
18 980645 Washer, Flat
3
/8 SS 4
19 170883 Washer, Lock
3
/8 4
20 85822A Screw,
3
/8-16 x
7
/8 8
21 980657 Washer, Lock ¼ 18
22 980205 Washer 2
23 57423A Snap Ring 2
24 80507A Key 2
25 899769 Casters 1
26 920260 Nut 4
27 980646 Washer 1
28 53087A Strap, Static 1
29 81104A Nut, ¼-20 SS 1
30 980652 Washer, Lock
5
/16 2
31 47905A Terminal 2
32 Page 30 Transaxle Parts ref.
Ref Part No. Description Qty
1
2
3
4
5
6
7
8
9
10
11
13
12
6
6
12
15
14
16, A,B,C,D
17
18
19
20
20
19
18
3
30
22
15
20
19
18
23
24
25
2
12
21
2
26
27
29
12
28
12
21
31
32
