Clarke
®
Operator's Manual IMAGE 26B Page -5-
Solution Pump 100 psi Adjustable By-pass
Solution Tank 30 Gallon
Capacity
Recovery Tank 30 Gallon
Capacity
Water Lift 76" Functional WL 150/CFM
Vacuum 2 Tangential discharge,
three-stage motors
Batteries 3 12V 195AH Batteries
Spray Jets Quick Change Nozzles
Brush Size 4" x 23"
Dimensions 48" x 26" x 43"
Weight (w/batteries) 650 lbs.
Shipping Weight 922 lbs.
Dimensions 56" x 28" x 46" (41.7 cu. ft.)
INTRODUCTION AND MACHINE SPECIFICATIONS
The IMAGE 26B is a one-piece, self-propelled carpet extractor designed for cleaning carpet. The machine applies
cleaning solution to the carpet and then removes the dirty solution and soil with a recovery tool.
IMAGE 26B, 36V
Features:
Easy to Operate
Interex cleaning system.
Brush pressure gauge.
Variable speed transaxle (forward and reverse)
Adjustable brush pressure.
Adjustable traverse speed.
Rugged 10-gauge mainframe.
Large capacity, compact size.
Easy access for serviceability.
Large recovery tank opening for easy cleaning.
Smooth 10", non marking, tread-less drive wheels.
Accessory tool connection.
No fatigue, dead man switch mounted on control handle.
Dual tangential discharge vac motors
Circuit breaker protection for traverse, brush, pump and vac motors.
Automatic shut-off when recovery tank is full.
Adjustable bypass pump.
Solution level indicator.
Low voltage battery protection (solution and brush stop when low voltage condition occurs)
