ICS-102/62 Intercom Panel Instruction Manual
3-11
Resistors & Resistor Packs
Designator Description Qty
R99 R103 1 OHM 1/4W CARBON FILM
5%
2
R101 2.2 OHMS 1/4W CARBON FILM
5%
1
R47 R48 22 OHMS 1/4W CARBON FILM
5%
2
R38 22 OHMS 1W CARBON FILM
5%
1
R18 R19 R57 R58 47 OHMS 1/4W CARBON FILM
5%
4
R46 82 OHMS 1/4W CARBON FILM
5%
1
R26 R31 R45 R56 100 OHMS 1/4W CARBON
FILM 5%
4
R39 R40 R41 R44 220 OHMS 1/4W CARBON
FILM 5%
4
R27 R30 240 OHMS 1/4W CARBON
FILM 5%
2
P1 5 OHMS TRIM POT 1
R17 R60 1K OHMS 1/4W CARBON FILM
5%
2
R88 1.2 OHMS 1/4W CARBON FILM
5%
1
R15 R24 R32 2.2K OHMS 1/4W CARBON
FILM 5%
3
R28 R29 2.4K OHMS 1/4W CARBON
FILM 5%
2
R63 R64 2.7K OHMS 1/4W CARBON
FILM 5%
2
R73 3.0K OHMS 1/4W CARBON
FILM 5%
1
R2 R3 R6 R7 R8 R85 R86 3.3K OHMS 1/4W CARBON
FILM 5%
7
R51 R52 R53 R54 R59 4.02K OHMS 1/8W METAL
FILM 1%
5
R23 R61 R76 4.7K OHMS 1/4W CARBON
FILM 5%
3
P2 5K OHMS TRIM POT 1
