ICS-102/62 Intercom Panel Instruction Manual
3-10
BILL OF MATERIALS
ICS-102/102T MAIN PCB
Capacitors
Designator Description Qty
C1 C2 27 PF CERAMIC 50V 5% 2
C55 47 PF CERAMIC 50V 10% 1
C44 C52 C53 C54 C59 C72 100 PF CERAMIC 50V 10% 6
C60 C82 200 PF CERAMIC 100V 5% 2
C41 6800 PF CERAMIC 50V 5% 1
C65 C66 .001 UF CERAMIC 30V 20% 2
C30 C31 C40 .0022 UF MYLAR 100V 5% 3
C32 .0047 UF MYLAR 50V 5% 1
C57 .0047 UF CERAMIC 50V 10% 1
C7 C11 C27 .01 UF CERAMIC 30V 20% 3
C13 .022 UF MYLAR 100V 10% 1
C56 .047 UF MONO 50V 10% 1
C9 C14 C25 C26 C35 C36
C47 C48 C49 C58 C61 C63
C3 C4 C5 C6 C8 C76 C79
C80 C81 C64 C67 C69 C70
C71 C73 C74 C75
.1 UF MONO 50V 10% 29
C42 .1 UF MONO 100V 10% 1
C45 C46 .22 UF MYLAR 100V 20% 2
C12 C18 1 UF CERAMIC 50V 10% 2
C3 C62 C77 C78 1 UF ALUMINUM NP 50V 10% 4
C33 2.2 UF ALUMINUM NP 50V 1
C38 C39 22 UF TANT. 16V 2
C28 C29 C37 C43 C50 C51 22 UF ALUMINUM 16V 20% 6
C84 C83 33 UF ALU LOW ESR 35V 20% 2
C10 47 UF ALUMINUM 16V 20% 1
C16 C17 100 UF ALUMINUM 25V 20% 2
C19 C20 220 UF ALUMINUM 25V 2
C68 1000 UF ALUMINUM 35V 1
C21 C22 C23 C24 4700 UF ALUMINUM 25V 4
