ICS-102/62 Intercom Panel Instruction Manual
3-20
BILL OF MATERIALS FOR ICS-102 SELECTOR SWITCH
PCB
Capacitors
Resistors & Resistor Packs
Diodes and Transistors
Integrated Circuits
Designator Description Qty
C5 0.001 uF Ceramic Disc 30 20% 1
C1 C3 C4 0.1 uF Monolithic 50 10% 3
C2 4.7 uF Aluminum 50 1
Designator Description Qty
R8 100 OHM 1/4 Carbon Film 5% 1
R2 R5 R6 4.7K OHM 1/4 Carbon Film 5% 3
R7 10K OHM 1/4 Carbon Film 5% 1
R1 R3 R4 100K OHM 1/4 Carbon Film 5% 3
Designator Description Qty
D1 D2 D3 D4 D5 D6 D7 D8
D9 D10 D11
Diode 1N4148 SIGNAL 10MA
75PIV
11
Designator Description Qty
IC5 Logic Chip 4001 CMOS 4 2 IN
NOR GATE
1
IC4 Logic Chip 4013 CMOS DUAL D
FF
1
IC1 IC2 IC3 Logic Chip 4094B CMOS SHIFT
REGISTER
3
IC6 Regulator 7805L POS 5V REG.
TO-92 PKG
1
