ICS-102/62 Intercom Panel Instruction Manual
3-31
Resistors
Diodes and Transistors
Designator Description Qty
R16 R22 R34 R35 R36 R40
R75
0 OHM 1/10 SMD 7
R30 2.2 OHM 1/10 SMD 5% 1
R4 47.5 OHM 1/10 SMD 1% 1
R46 R47 R48 R49 R50 R51
R52 R53 R54
221 OHM 1/10 SMD 1% 9
R38 301 OHM 1/10 SMD 1% 1
R3 392 OHM 1/10 SMD 1% 1
R29 R19 R55 604 OHM 1/10 SMD 1% 3
R43 R56 R58 R59 R60 R62
R63R64 R65 R67 R68 R70
R71 R72 R73 R74 R69
1.00K OHM 1/10 SMD 1% 17
R37 2.74K OHM 1/10 SMD 1% 1
R39 3.24K OHM 1/10 SMD 1% 1
R1 R6 R9 R10 R11 R12 R13
R24 R25 R32
4.75K OHM 1/10 SMD 1% 10
R33 R41 R42 R44 R45 R27 4.75K OHM 1/10 SMD 1% 6
R28 4.99K OHM 1/10 SMD 1% 1
R17 7.50K OHM 1/IO SMD 1% 1
R26 R18 75.0K OHM 1/10 SMD 1% 2
Designator Description Qty
D1 Diode BAV99 DUAL DIODE...
SMD
1
