DGD intelligent spindles
5
5.2.3 Size 3 – 1× transducer
Smallest scribed circle diameter in mm
Designation Order No. Torque
Nm
Speed Spring
travel
min.
axis
distance
Length
Weight Spring
chuck
max. min. RPM mm mm mm kg + flange
3BTSE-3B300A-3M2B-3ZB 947656A0
300 50
453
50
3/4"
81 589 14.1
910613
S308436
3BTSE-3B300A-3VM2B 947657A9
1)
1) On request
421 59 584 15.2 S308439
3BTSE-3B300A-3WM2B 947658A8
1)
437 25
81
678 17.8 – 929065
3BUTSE-3B300A-3M2B-3ZB 947659A7
1)
453
50
417 16.1
910613
S308436
3BUTSE-3B300A-3VM2B 947660A4
1)
421 59 412 17.2 S308439
3BUTSE-3B300A-3WM2B 947661A3
1)
437 25 81 506 19.8 – 929065
Quantity Attachment
DGD-IS Centric Offset Angle head
2815981
3946994
4 116 84 116
5 139 102 139
6 164 122 164
7 189 138 189
