77h_PowerDistributionBox-en.fm, 06.09.2011 P2077SB/EN 2011-09 43
Power distribution box PDB-CPS…
11
11.5.2 General technical dataCPS3
11.5.3 Electrical DataCPS3
Features Data
Order No. 961112
Weight G 3650
Protection category IP20
Cooling type Convection
(self-cooling)
Service life, operating h 40.000
On/Off switching cycles 5.000.000
Usability period if stored h 100,000 (approx. 11 years)
Features Data
Supply voltage power VAC 3 × 270 ±10%
Frequency Hz 50 – 60
Rated current A 3 × 7
Peak current, momentary in RMS mode A 3 × 25
Rated output VA 3000
Peak power, momentary in RMS mode VA 30.000
Output voltage of intermediate power circuit VDC 380 ±10 %
Nominal output current (380 VDC) A 8
Output current, maximum (5 s) A 80
Control supply voltage VDC 24 ±10 %
Input current (without external load) A 0.5
Control voltage / Output voltage VDC 24 ±10 %
Output current, maximum (24 VDC) A 8
