77h_PowerDistributionBox-en.fm, 06.09.2011 P2077SB/EN 2011-09 45
Power distribution box PDB-CPS…
11
11.5.7 Plug connectors and configuration
"XS1 Power in"
Required connector type:
Phoenix Power Combicon PC6/4-ST-10,16
Order No. 961175
"XS21 Power out"
Power supply DGD-IS 380 VDC
Required connector type:
Phoenix Power Combicon IPC6/3-ST-10,16
Order No. 961188
"XS22" TSE/TUSE
24 V supply and Enable servo signal (end stage release signal) to DGD-IS
Required connector type:
Phoenix Combicon MSTB2.5/3-STF-5.08
Part no. S959935
WARNING!
• Unplugging the system cable while still live may generate an electric arc and cause serious burns.
• The contacts may become damaged.
➔ Switch off the power supply to the PDB-CPS… before unplugging or inserting the system cable!
Contact Signal Description
L1 L1
Supply voltage 3 × 270 VACL2 L2
L3 L3
PE PE Earth conductor, connection to housing
Contact Signal Description
IC+ +380 VDC Intermediate circuit voltage +380 VDC ±10 %
IC- 0 VDC Intermediate circuit voltage 0 V
PE PE Earth conductor, connection to housing
Contact Signal Description
24 V +24 V Out Supply TSE/TUSE,
24 V +10 %,
max. 4 A
(8 DGD-IS)
Enab SV Enable servo Enable servo output;
End stage release;
Active when no errors or
Emergency stop pending
24 VDC, max. 0.3 A
0VDC 0V Supply TSE/TUSE, 0 V
