14
P The top of the child’s head must be at least
1 in. (2.5 cm) below the top of the car seat’s
Headrest, as shown in Figure 1.
NOTE: If the top of the child’s head is less
than 1 in. (2.5 cm) below the top of the
Headrest in the highest adjustment position,
your child is too large for using this car seat
Rear-Facing and must be transitioned to
using this car seat Forward-Facing.
P The Shoulder Harness Straps must be
through Shoulder Harness Slots at or
below and closest to the child’s shoulders,
as shown in Figure 2.
P The Crotch Strap should be through
the inner Crotch Strap Slot.
P Bottom of Headrest is at or above the
Shoulder Harness Slots in Use.
P Harness is fully secured and snugly adjusted
around child.
P Car Seat must be adjusted to recline position
2 or 3, with the Rear-Facing Reference Line
appropriate for the child’s weight parallel to
the ground.
P Car seat should not move more than 1” in
any direction when grasped above the belt
path and pushed.
Figure 1
Figure 2
