Figure 21
Figure 20
Adjusting Headrest
Step 1
Press the button on the Headrest Adjuster on the
right-hand side of the seat (when facing front
of seat) (1) and raise or lower the Headrest into
the desired position (2) as shown in Figure 19.
Step 2
Check for proper adjustment of Headrest.
The bottom of the Headrest must ALWAYS be
at or above the Harness Slots in use.
Rear-Facing: The top of the child’s head
must be at least 1 in. (2.5 cm) below the
top of the car seat’s Headrest, as shown
in Figure 20. If the top of the child’s head
is less than 1 in. (2.5 cm) below the top
of the Headrest in the highest adjustment
position, your child is too large for
using this car seat Rear-Facing and must
be transitioned to using this car seat
Forward-Facing.
Forward-Facing: The tops of the child’s
ears must be below the top of the car
seat’s Headrest, as shown in Figure 21.
If the tops of the child’s ears are above
the top of this car seat’s Headrest in the
highest adjustment position, your child is
too large for this car seat.
