89
Forward-Facing Rigid
LATCH Storage
To store the Rigid LATCH Connectors, pull
and hold the Rigid LATCH Adjustment Handle
while pulling the Rigid LATCH Connectors
into the seat until they stop as shown in
Figure 140.
Top Tether Storage
Removal: Remove Instruction Manual and
Tether belt from back of seat. Pull in and
hold retention spring on Tether Hook, then
remove hook from storage bar as shown in
Figure 141, then replace Instruction Manual.
Storage: Remove Instruction Manual from
back of seat. Hook Tether Hook around
storage bar as shown in Figure 142, fold
Top Tether belt and insert into Tether Storage.
Replace Instruction Manual.
Figure 140
Figure 141
Figure 142
