39
Figure 44
Figure 43
Step 3
If the vehicle seat back is adjustable, make
sure the seat back is locked in a more upright
position. Refer to vehicle owner’s manual for
recommended seat back angle. DO NOT
install or use this car seat while the vehicle
seat back is excessively reclined, as shown in
Figure 43.
Step 4
Open both Rear-Facing Belt Lock-offs, as
shown in Figure 44.
Check that both the top and bottom portions
of each Rear-Facing Lock-off are clear of the
Rear-Facing Belt Path.
Step 5
Remove Rear-Facing LATCH Belt from its
storage location under the Seat Cushion, see
“Rear-Facing LATCH Storage” on page 87.
Lengthen each side of Rear-Facing LATCH
Belt by pressing adjuster release button while
pulling belt to extend the length of Rear-
Facing LATCH Belt as shown in Figure 45.
Figure 45
