76
Step1
Loosen Harness:
• While lifting up on Harness Adjuster
Tab, pull out on Shoulder Harness Straps
as shown in Figure 113.
Step 2
Place child in car seat with their back
flat against the Seat Back as shown in
Figure 114.
Step 3
Place child’s arms through Shoulder Harness
Straps and position the Straps over child’s
shoulders and thighs.
Step 4 (for Rear-Facing use only)
Recheck that the Rear-Facing Level
Reference Line appropriate for the child’s
weight is parallel to the ground, as shown
in Figure 115, and adjust if necessary. See
“Installing/Removing Rear-Facing Car Seat”
on page 35 if adjustment is required.
Figure 113
Figure 114
Child seat is properly reclined in Rear-Facing mode when the line
appropriate for the child’s weight is parallel to the ground
USE THIS LINE FOR INFANTS UNDER 22 lbs (10 kg)
USE THIS LINE FOR CHILDREN BETWEEN 22 - 50 lbs (10 - 22.7 kg)
Rear-Facing
1
3
• To Release Rigid LATCH Connectors: Fully extend Connectors, then pull Red Rigid LATCH Release Handles.
2
Forward-Facing Rear-Facing
Child seat is properly reclined in Rear-Facing mode when the line
appropriate for the child’s weight is parallel to the ground
USE THIS LINE FOR INFANTS UNDER 22 lbs (10 kg)
USE THIS LINE FOR CHILDREN BETWEEN 22 - 50 lbs (10 - 22.7 kg)
Rear-Fac ing
1
• To Release Rigid LATCH Connectors: Fully extend Connectors, then pull Red Rigid LATCH Release Handles.
Forwa rd-Facing
