Step 6
Check Position of Headrest:
The bottom of the Headrest must ALWAYS
be at or above the Harness Slots in use.
Rear-Facing: The top of the child’s head
must be at least 1 in. (2.5 cm) below the
top of the car seat’s Headrest, as shown
in Figure 118. If the top of the child’s
head is less than 1 in. (2.5 cm) below
the top of the Headrest in the highest
adjustment position, your child is too
large for using this car seat Rear-Facing
and must be transitioned to using this
car seat Forward-Facing.
Forward-Facing: The tops of the child’s
ears must be below the top of the car
seat’s Headrest, as shown in Figure 119.
If the tops of the ears are above the top
of this car seat’s Headrest in the highest
adjustment position, your child is too
large for this car seat.
See “Adjusting Headrest” on page 27 to
change Headrest position.
