80
Step 9
Pull Harness Adjuster Strap to snugly adjust
Harness Straps as shown in Figure 123.
• Check that Harness Straps are snug on
shoulder and thighs.
• A snug Harness should not allow any
slack. It lies in a relatively straight line
without sagging. It does not press on the
child’s flesh or push the child’s body into
an unnatural position.
NOTE: If Harness cannot be snugly adjusted
as described above, see step 3 of “Shoulder
Harness Rethreading” on page 33 to make
the harness smaller.
Step 10
Close Chest Clip and position Chest Clip at
arm pit level as shown in Figure 124.
Figure 123
Figure 124
