Clevo P150e

Upgrading The Computer
Upgrading the Optical Device (Model C) 6 - 5
6
Upgrading the Optical Device (Model C)
1. Locate the secondary hard disk bay cover and remove screws & .
2. Remove the hard disk bay cover.
3. Remove the screw at point , and use a screwdriver to carefully push out the
optical device out of the bay.
4. Reverse the process to install any new optical (CD/DVD) device.
Figure 6 - 3
Removing the
Optical (CD/DVD)
Device
1
2
3
1
2
3
