Clevo P150e

Upgrading The Computer
6 - 10 Upgrading the Hard Disk Drive(s)
6
Inserting the Hard Disk Into the Primary HDD Bay
1. Make sure the HDD assembly is aligned with the black taped area .
2. When aligned, carefully insert the HDD assembly into the case so that the
connectors line up.
3. Replace the hard disk bay covers and screws.
Figure 6 - 7
Primary HDD
Assembly Insertion
1
2
2
1 1
