Introduction

1 - 2 Overview

1.Introduction

Specifications



Latest Specification Information

The specifications listed here are correct at the

time of sending them to the press. Certain items

(particularly processor types/speeds) may be

changed, delayed or updated due to the manu-

facturer's release schedule. Check with your

service center for more details.



CPU

The CPU is not a user serviceable part. Ac-

cessing the CPU in any way may violate your

warranty.

Processor Options

Intel® Core™ i7 Processor Extreme Edition

i7-2920XM (2.50GHz)

8MB L3 Cache, 32nm, DDR3-1600MHz, TDP 55W

Intel® Core™ i7 Processor

i7-2820QM (2.30GHz)

8MB L3 Cache, 32nm, DDR3-1600MHz, TDP 45W

i7-2720QM (2.20GHz) , i7-2630QM (2.0GHz)

6MB L3 Cache, 32nm, DDR3-1600MHz, TDP 45W

i7-2520M (2.50GHz)

3MB L3 Cache, 32nm, DDR3-1333MHz, TDP 35W

Memory

*Four 204 Pin SO-DIMM Sockets Supporting DDR3 1333/

1600** MHz Memory Modules

Memory Expandable up to 16GB

Compatible with 2GB or 4GB Modules

*Note: Four SO-DIMMs are only supported by Quad-Core

CPUs; Dual-Core CPUs support two SO-DIMMs maximum

**Note:

1600 MHz Memory Modules

are only supported by

Quad-Core CPUs to a maximum of two SO-DIMMs

BIOS

AMI BIOS (32Mb SPI Flash-ROM)

LCD

P170HM:

17.3" (43.94cm) FHD (1920 * 1080)

P170HM3:

17.3" (43.94cm) FHD (1920 * 1080), 120Hz

Support 3D solution with NV 3D VISION Kit (Shutter Glasses

Only)

Built-in 3D IR Emitter

Core Logic

Intel® HM67 Chipset

Pointing Device

Built-in Touchpad (scrolling key functionality integrated)

Keyboard

Full-size “WinKey” keyboard with numeric keypad

Video Adapter

P170HM:

nVIDIA® GeForce GTX 485M PCIe Video Card

2GB GDDR5 Video RAM on board
