Clevo P170HM

Disassembly
Removing the Battery 2 - 5
2.Disassembly
Removing the Battery
1. Turn the computer off, and turn it over.
2. Slide the latch in the direction of the arrow (Figure 1a
).
3. Slide the latch in the direction of the arrow, and hold it in place (Figure 1a
).
4. Lift the battery out in the direction of the arrow (Figure 1b & Figure 1c
).

3. Battery
1
2
6
3
4
a.
b.
2
1
3
4
c.
3
Figure 1
Battery Removal
a. Slide the latch and hold in
place.
b. Slide the battery in the di-
rection of the arrow.
c. Lift the battery out in the
direction of the arrow.
