Clevo P170HM

Introduction
1 - 6 External Locator - Left Side & Rear View
1.Introduction
External Locator - Left Side & Rear View
Figure 4
Left Side View
1. RJ-45 LAN Jack
2. 2 * USB 3.0 Ports
3. 1 * USB 2.0 Port
4. Mini-IEEE 1394a
Port
5. Multi-in-1 Card
Reader
1
2
3
4
5
2
Figure 5
Rear View
1. Vent/Fan Intake
2. eSATA/USB 2.0
Combo Port
3. HDMI-Out Port
4. DVI-Out Port
5. DC-In Jack
6. Security Lock Slot
2
3
5
1
4
1
6
