ClimateMaster TMW036 - TMW Series Wiring Diagram Matrix

CLIMATEMASTER WATER-SOURCE HEAT PUMPS
Tranquility
®
Water-to-Water (TMW) Series
Rev.: 04/15/16
20
ClimateMaster Water-Source Heat Pumps
TMW Series Wiring Diagram Matrix
Model
Wiring Diagram
Part Number
Electrical Control DDC Agency
TMW036-060
96B0223N02
208-230/60/1,
265/60/1
(TMW036 ONLY)
CXM MPC/LON
ETL
96B0223N03
208-230/60/3,
460/60/3,
575/60/3
96B0224N01
208-230/60/1
(TMW060 ONLY)
96B0223N06
208-230/60/1,
265/60/1
(TMW036 ONLY)
DXM MPC/LON
96B0223N07
208-230/60/3,
460/60/3,
575/60/3
96B0224N02
208-230/60/1
(TMW060 ONLY)
TMW120
96B0225N02 208-230/60/1
CXM
MPC/LON
96B0225N03
208-230/60/3,
460/60/3,
575/60/3
MPC/LON
96B0225N05 208-230/60/1
DXM
MPC/LON
96B0225N06
208-230/60/3,
460/60/3,
575/60/3
MPC/LON
TMW170
96B0226N01
208-230/60/3,
460/60/3,
575/60/3
CXM
-
96B0226N03 LON
96B0226N05 MPC
96B0226N08
DXM
-
96B0226N10 LON
96B0226N12 MPC
TMW340
96B0227N01
208-230/60/3,
460/60/3,
575/60/3
CXM
-
96B0227N03 LON
96B0227N05 MPC
96B0227N09
DXM
-
96B0227N11 LON
96B0227N13 MPC
AUX WD
TMW036-060
96B0146N01
All CXM/DXM
MPC
96B0146N02 LON
TMW120
96B0146N05 MPC
96B0146N06 LON
All current 60 Hz wire diagrams can be downloaded at www.climatemaster.com/commercial-wiring
