CLIMATEMASTER WATER-SOURCE HEAT PUMPS
Tranquility
®
Water-to-Water (TMW) Series
Rev.: 04/15/16
36
ClimateMaster Water-Source Heat Pumps
If a UPS condition occurs, the control will immediately
go to UPS warning. The status LED will remain on as if
the control is in normal mode. Outputs of the control,
excluding LED and alarm relay, will NOT be affected
by UPS. The UPS condition cannot occur during a
compressor off cycle. During UPS warning, the alarm
relay will cycle on and off. The cycle rate will be “on” for
5 seconds, “off” for 25 seconds, “on” for 5 seconds, “off”
for 25 seconds, etc.
UPS warning code = 8
Swapped LT1/LT2 thermistors: During test mode, the
control monitors to see if the LT1 and LT2 thermistors are
in the appropriate places. If the control is in test mode,
the control will lockout with code 9 after 30 seconds if:
a. The compressor is on in the cooling mode and the
LT1 sensor is colder than the LT2 sensor, or:
b. The compressor is on in the heating mode and the
LT2 sensor is colder than the LT1 sensor.
Swapped LT1/LT2 thermistor code = 9.
ESD (DXM only): The ESD (Emergency Shut Down)
mode can be enabled from an external common signal
to terminal ESD to shut down the unit. The green status
light will ash code 3 when the unit is in ESD mode.
ESD mode = code 3 (green “status” LED)
CXM/DXM CONTROLS
Diagnostic Features - The LED on the CXM board
advises the technician of the current status of the CXM
control. The LED can display either the current CXM
mode or the last fault in memory if in test mode. If there
is no fault in memory, the LED will ash Code 1 (when in
test mode).
The green status LED and red fault LED on the DXM
board advise the technician of the current status of the
DXM control. The status LED will indicate the current
mode that the DXM control is in. The fault LED will
ALWAYS ash a code representing the LAST fault in
memory. If there is no fault in memory, the fault LED will
ash Code 1. The yellow test LED will turn on when in
test mode.
CXM/DXM Control Start-up Operation - The control
will not operate until all inputs and safety controls are
checked for normal conditions. The compressor will have
a 5 minute anti-short cycle delay at power-up. The rst
time after power-up that there is a call for compressor,
the compressor will follow a 5 to 80 second random start
delay. After the random start delay and anti-short cycle
delay, the compressor relay will be energized. On all
subsequent compressor calls, the random start delay is
omitted.
Environment -This unit is designed for indoor installation
only. Do not install in an area subject to freezing or where
humidity levels can cause cabinet condensation.
Power Supply - A voltage variation of +/- 10% of
nameplate utilization voltage is acceptable.
Operation and performance is primarily dependent upon
water temperatures, water ow rates and ambient air
temperature. This water to water heat pump is capable of
operating over a wide temperature range and with ow
rates of between 1.5 GPM (.1 l/s) and 3 GPM (.19 l/s) per
ton, however usually no more than one of these factors
may be at a minimum or maximum level at a time.
The commissioning table indicates water temperatures
which are suitable for initial unit commissioning in an
environment where the ow rate and water temperature
is not yet stable and to avoid nuisance shut down of the
units freeze and refrigerant pressure safeties.
The operating table indicates the maximum and
minimum ranges of the unit.
For more speci c unit performance reference the product
catalog, the submittal data sheets or contact your
supplier for assistance.
BUILDING COMMISSIONING
Cooling Heating
Unit Size 036 060/120 170/340 036 060/120 170/340
Source Min/Max 50/110 50/120 50/90 30/80 30/80 50/70
Load Min/Max 60/80 60/90 60/90 60/120 60/120 80/120
Ambient Min/Max 45/110 39/85
BUILDING OPERATING
Cooling Heating
Unit Size 036 060/120 170/340 036 060/120 170/340
Source Min/Max 50/120 50/120 50/110 20/80 20/80 20/70
Load Min/Max 50/90 50/90 50/90 60/130 60/130 60/120
Ambient Min/Max 45/110 39/85
