CLIMATEMASTER WATER-SOURCE HEAT PUMPS
Tranquility
®
Water-to-Water (TMW) Series
Rev.: 04/15/16
48
ClimateMaster Water-Source Heat Pumps
Revision History
Date: Item: Action:
04/15/16 Text Updated
10/16/15 Wiring Diagram Matrix Updated
06/23/14 Water Quality Table Updated
11/09/12
POE Oil Warning Added
Water Quality Table Updated
11/14/11 TMW170 & 340 Unit Dimensional Data Updated
08/09/11 Unit Maximum Working Water Pressure Updated to Refl ect New Safeties
01/03/11 Format - All Pages Updated
10/06/10 Start-Up Log Sheet Added
07/26/10 Wiring Diagrams Updated
06/11/10 Format - All Pages Updated
04/08/10 Electrical and Operating Pressures Tables Updated
11/05/09 Warranty Updated
09/15/09 Safety Features - CXM/DXM Control Section Updated
06/01/09 Operating Pressures Heating Table Updated
05/07/09 ‘Unit Starting & Operating Conditions’ Section & Table Edited and renamed ‘Unit Commissioning and Operating Conditions’
04/21/09 Physical Data Table Water Volume Data Updated
04/21/09
Water-Loop & Ground-Loop Heat Pump Applications Sections,
Electrical Line Voltage Section, Safety Feature Section
Verbiage Updated
04/02/09 First Published
